Library UHF RFID label · NXP UCODE 9 (RT-S144)
This 95x3 mm UHF book label was drawn out into a hairline strip precisely so librarians can hide it deep in the binding or between pages. Powered by NXP UCODE 9 with a 96-bit EPC and 96-bit factory-locked TID (includes a 48-bit unique serial number) under EPCglobal Class 1 Gen 2, it handles circulation scans, stocktakes and gate security; asset teams use it for discreet marking too.
At a glance
- RFID Chip
- NXP UCODE 9
- Label Size
- 95mm*3mm
- Protocol
- ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
- Memory
- 96-bit factory-locked TID (includes a 48-bit unique serial number), 96 bits EPC, 0 bit User Memory
- Face Material
- Art-Paper, PET，PP synthetic paper & Other Customize Face Material
- Product
- UHF RFID Library Label
Quote reply within 24 hours
Free samples — freight collect
Share your quantity, surface, printing and encoding requirements. We’ll confirm the configuration, volume pricing and sample availability.
Supplied by Rivotag through partner production lines.Technical information
Full specifications
Catalogue values describe this construction. Confirm any changes to chip, size, material, printing or encoding in your quotation.
Overview
| Product | UHF RFID Library Label |
|---|---|
| RFID Chip | NXP UCODE 9 |
| Label Size | 95mm*3mm |
| Face Material | Art-Paper, PET，PP synthetic paper & Other Customize Face Material |
| Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
| Memory | 96-bit factory-locked TID (includes a 48-bit unique serial number), 96 bits EPC, 0 bit User Memory |
| Applications | Library management, Asset management, General purpose |
| Key Benefits | Fast reading,Multi-reading, Traceability |
Customized services Details
| Customizable Label Size | Yes |
|---|---|
| Printing | Thermal transfer printing，Silk Screen Printing，and other custom printing. |
| Data initialization | Encoding |
Storage Environment Requirements
| Operating Temperature/Humidity | -0～60℃ / 20%～80% RH |
|---|---|
| Storage Temperature/Humidity | 20～30℃ / 20%～60% RH |
| Shelf Life | 1 year in anti-static bag at 20～30℃ / 20% ～60% RH |
| ESD Voltage Immunity | 2 kV (HBM) |
| Bending Diameter | ＞ 50mm |
| Other application environment requirements | Your environmental requirements for RFID labels will affect our selection and design of labels. For example, if you are going to apply RFID labels to special environments: high temperature & low temperature environment; high acid & high alkaline environment, please inform our product design team that we will customize unique RFID products for you within 3 working days. |
- Applications
- Library management, Asset management, General purpose
- Key Benefits
- Fast reading,Multi-reading, Traceability
Borrowers should notice the book, never the tag. That thinking shaped this library label into a 95x3 mm hairline that slides into the page gutter or under a spine wrap — out of sight, out of reach, and immune to casual peeling.
Behind the paper sits an NXP UCODE 9 chip speaking ISO/IEC 18000-6C (EPCglobal Class 1 Gen 2). Its 96-bit EPC uniquely identifies every volume for check-in, check-out and security gates, while multi-read support turns end-of-year stocktakes from weeks of shelf-walking into hours of scanning. Construction options cover art paper, PET or PP synthetic; the label operates from 0 to 60 °C and flexes safely beyond a 50 mm bend diameter.
Ordering & customization
Length, face stock, printing and chip choice are all adjustable, and we pre-encode EPC/TID data so tags arrive ready to shelve. Sampling is free with freight-collect delivery in 3-5 working days; volume production completes 7-15 days after artwork approval on ISO 9001 partner lines, and quotes are answered within 24 hours.
Chip memory reference: NXP UCODE 9 specification.
