UHF RFID label · 75×40 mm (RT-L125)
RT-L125

Validate this construction on your material with samples before a volume order.

Labels for Different Frequencies

UHF RFID label · 75×40 mm (RT-L125)

A 75×40 mm UHF label faced with direct thermal paper: heat alone develops the print, so no ribbon or ink is ever loaded — quicker output and lower running costs at supermarket receipt counters and ribbon-unfriendly stations. The Q-Star 7U chip supplies a 128-bit EPC, 128-bit user memory and 48-bit TID over ISO/IEC 18000-6C.

At a glance

RFID Chip
Q-Star 7U
Label Size
75mm*40mm
Protocol
ISO/IEC 18000-6C, EPCglobal Class Gen 2
Memory
48 bits TID,128 bits EPC, 128 bits User Memory
Face Material
Thermal paper
Product Model
RT-L125
Full specifications
Request a quote Request samples

Quote reply within 24 hours

Free samples — freight collect

Pricing matched to your project.

Share your quantity, surface, printing and encoding requirements. We’ll confirm the configuration, volume pricing and sample availability.

Supplied by Rivotag through partner production lines.

Technical information

Full specifications

Download specification summary

Catalogue values describe this construction. Confirm any changes to chip, size, material, printing or encoding in your quotation.

Overview

Product ModelRT-L125
RFID ChipQ-Star 7U
Label Size75mm*40mm
Antenna Size70mm*14mm
Face MaterialThermal paper
ProtocolISO/IEC 18000-6C, EPCglobal Class Gen 2
Memory48 bits TID,128 bits EPC, 128 bits User Memory
ApplicationsSupermarket receipt, Printing situations where it is inconvenient to install ribbons
Key BenefitsFast reading,Multi-reading, Traceability,Transferable

Customized services Details

Customizable Label SizeYes
PrintingThermal transfer printing，Silk Screen Printing，and other custom printing.
Data initializationEncoding

Storage Environment Requirements

Operating Temperature/Humidity-0～60℃ / 20%～80% RH
Storage Temperature/Humidity20～30℃ / 20%～60% RH
Shelf Life1 year in anti-static bag at 20～30℃ / 20% ～60% RH
ESD Voltage Immunity2 kV (HBM)
Bending Diameter＞ 50mm
Other application environment requirementsYour environmental requirements for RFID labels will affect our selection and design of labels. For example, if you are going to apply RFID labels to special environments: high temperature & low temperature environment; high acid & high alkaline environment, please inform our product design team that we will customize unique RFID products for you within 3 working days.
Applications
Supermarket receipt, Printing situations where it is inconvenient to install ribbons
Key Benefits
Fast reading,Multi-reading, Traceability,Transferable

Ribbons run out; thermal paper does not need them. The face of this 75×40 mm label darkens directly under the print head’s heat, producing text and barcodes with no ink, no ribbon and no consumable swaps — which is why the format suits supermarket receipt printing and any station where loading a ribbon is impractical.

Beneath the thermal face runs a 70×14 mm antenna with a Q-Star 7U chip: 128-bit EPC, 128 bits of user memory and a 48-bit TID over ISO/IEC 18000-6C / EPCglobal Gen 2, read quickly and in groups for traceability work. The construction is also transferable, and operating range covers 0–60 °C at 20–80% RH.

Ordering and customization

Sourced through ISO 9001 partner lines, the label ships with chip, size, face material, printing and EPC/TID encoding matched to your equipment. We reply to quotes within 24 hours, dispatch free samples freight collect in 3–5 working days, and finish mass production 7–15 days after artwork approval.

Ordering this product

Sampling, quotations and supply through Rivotag.

How fast will I get a quotation?
We reply to every enquiry within 24 hours with a specific recommendation — chip, antenna, face material and adhesive — plus tiered unit pricing for the quantities you request.
Can I get samples before ordering?
Yes. Samples are free of charge (freight collect) and dispatched within 3–5 working days, so you can verify read performance on your own material before committing to production.
What is the production lead time?
Mass production typically ships in 7–15 days after artwork approval. Our partner factories run 30+ production lines with a combined capacity of about 1.5 billion tags per year.
Are you the manufacturer?
We are an independent supplier, not the factory. Production runs on audited partner lines in China that hold ISO 9001 certification and ARC-certified standard designs; we handle engineering review, sampling, QC and logistics, and remain your single accountable contact.
Can you customize size, chip, printing and encoding?
Yes — size, chip (Impinj, NXP, Alien and more), face material, adhesive, printing and EPC/TID encoding are all customizable. A custom antenna design typically takes 3 working days.
How is quality controlled?
Partner lines run CCD vision inspection on every roll, Voyantic RFID performance testing, and 100% read verification after encoding, under an ISO 9001 quality system. We release shipment only after QC data is confirmed.
