UHF RFID label · 101×50 mm · NXP UCODE 8 (RT-L134)
A 101x50 mm UHF label faced with direct thermal paper, so graphics develop under the printhead alone — no ribbon, no ink, faster label changes at busy stations. Suited to supermarket receipts and point-of-use printing, it houses an NXP UCODE 8 chip with 128-bit EPC and a 94x24 mm antenna for dependable reads.
At a glance
- RFID Chip
- NXP UCODE 8
- Label Size
- 101mm*50mm
- Protocol
- ISO/IEC 18000-6C, EPCglobal Class Gen 2
- Memory
- 48 bits TID,128 bits EPC, 0 bit User Memory
- Face Material
- Thermal paper
- Product Model
- RT-L134
Quote reply within 24 hours
Free samples — freight collect
Share your quantity, surface, printing and encoding requirements. We’ll confirm the configuration, volume pricing and sample availability.
Supplied by Rivotag through partner production lines.Technical information
Full specifications
Catalogue values describe this construction. Confirm any changes to chip, size, material, printing or encoding in your quotation.
Overview
| Product Model | RT-L134 |
|---|---|
| RFID Chip | NXP UCODE 8 |
| Label Size | 101mm*50mm |
| Antenna Size | 94mm*24mm |
| Face Material | Thermal paper |
| Protocol | ISO/IEC 18000-6C, EPCglobal Class Gen 2 |
| Memory | 48 bits TID,128 bits EPC, 0 bit User Memory |
| Applications | Supermarket receipt，Printing situations where it is inconvenient to install ribbons |
| Key Benefits | Fast reading,Multi-reading, Traceability,Transferable |
Customized services Details
| Customizable Label Size | Yes |
|---|---|
| Printing | Thermal transfer printing，Silk Screen Printing，and other custom printing. |
| Data initialization | Encoding |
Storage Environment Requirements
| Operating Temperature/Humidity | -0～60℃ / 20%～80% RH |
|---|---|
| Storage Temperature/Humidity | 20～30℃ / 20%～60% RH |
| Shelf Life | 1 year in anti-static bag at 20～30℃ / 20% ～60% RH |
| ESD Voltage Immunity | 2 kV (HBM) |
| Bending Diameter | ＞ 50mm |
| Other application environment requirements | Your environmental requirements for RFID labels will affect our selection and design of labels. For example, if you are going to apply RFID labels to special environments: high temperature & low temperature environment; high acid & high alkaline environment, please inform our product design team that we will customize unique RFID products for you within 3 working days. |
- Applications
- Supermarket receipt，Printing situations where it is inconvenient to install ribbons
- Key Benefits
- Fast reading,Multi-reading, Traceability,Transferable
Ribbon changes stall busy print stations, so this label removes the ribbon altogether. Its face is direct thermal paper, developing text and barcodes through heat alone — a saving on consumables that keeps supermarket receipt printers and weigh-scale stations moving. Print, peel, apply, done.
RFID capability comes from an NXP UCODE 8 chip with a 128-bit EPC and 48-bit TID, coupled to a generous 94x24 mm antenna across the 101x50 mm face. Conformance with ISO/IEC 18000-6C means any EPC Gen 2 reader collects these labels in bulk as trolleys and totes roll past. Thermal stock prefers moderate conditions: store rolls at 20-30 °C and operate between 0 and 60 °C.
Ordering & customization
We can resize the die-cut, swap chips, change face stock or add silk-screen branding, and EPC/TID encoding is available before shipment. Free samples go out freight collect within 3-5 working days; production completes 7-15 days after artwork approval on ISO 9001 partner lines, with quotes answered inside 24 hours.
