Woven UHF RFID textile tag · 80×30 mm · Alien Higgs 9 (RT-T104)
An 80x30 mm sew-in textile label built on single-sided ribbon for a softer hand feel at lower cost. The nylon face carries printed care or brand detail, while the Alien Higgs 9 chip offers an expandable 96-496 bit EPC plus 688 bits of user memory over ISO/IEC 18000-6C — room for serial data other clothing tags cannot hold.
At a glance
- RFID Chip
- Alien Higgs 9
- Label Size
- 80mm*30mm
- Protocol
- ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
- Memory
- 48 bits TID, 96-496 bits EPC, 688 bits User Memory
- Face Material
- Nylon
- Product
- RFID Textile / Woven/ Clothing/ Satin Label
Quote reply within 24 hours
Free samples — freight collect
Share your quantity, surface, printing and encoding requirements. We’ll confirm the configuration, volume pricing and sample availability.
Supplied by Rivotag through partner production lines.Technical information
Full specifications
Catalogue values describe this construction. Confirm any changes to chip, size, material, printing or encoding in your quotation.
Overview
| Product | RFID Textile / Woven/ Clothing/ Satin Label |
|---|---|
| RFID Chip | Alien Higgs 9 |
| Label Size | 80mm*30mm |
| Antenna Size | 70mm*17mm |
| Face Material | Nylon |
| Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
| Memory | 48 bits TID, 96-496 bits EPC, 688 bits User Memory |
| Applications | Apparel/Clothing management |
| Key Benefits | Labels are lightweight, soft and can be sewn. Fast&Multi-reading, Traceability |
Customized services Details
| Customizable Label Size | Yes |
|---|---|
| Printing | Thermal transfer printing，Silk Screen Printing，and other custom printing. |
| Data initialization | Encoding |
Storage Environment Requirements
| Operating Temperature/Humidity | -0～60℃ / 20%～80% RH |
|---|---|
| Storage Temperature/Humidity | 20～30℃ / 20%～60% RH |
| Shelf Life | 1 year in anti-static bag at 20～30℃ / 20% ～60% RH |
| ESD Voltage Immunity | 2 kV (HBM) |
| Bending Diameter | ＞ 50mm |
| Other application environment requirements | Your environmental requirements for RFID labels will affect our selection and design of labels. For example, if you are going to apply RFID labels to special environments: high temperature & low temperature environment; high acid & high alkaline environment, please inform our product design team that we will customize unique RFID products for you within 3 working days. |
- Applications
- Apparel/Clothing management
- Key Benefits
- Labels are lightweight, soft and can be sewn. Fast&Multi-reading, Traceability
Double-sided woven labels are stiffer and pricier than most garments need. This 80x30 mm textile tag takes the single-sided route instead: softer to the touch, kinder to the budget, and still tough enough to be sewn permanently into clothing so the tag can never fall away from the item it identifies.
The electronics are the interesting part. An Alien Higgs 9 chip on a 70x17 mm antenna provides an EPC bank expandable from 96 to 496 bits plus 688 bits of user memory — space for batch, style and process data most clothing tags cannot carry — under ISO/IEC 18000-6C (EPCglobal Class 1 Gen 2). Every label holds a unique electronic code for secure identification, operating from 0 to 60 °C.
Ordering & customization
Widths, lengths, chip choice, face weave and printing all adjust to your garment line, and we encode EPC/TID data before shipment. Free samples travel freight collect in 3-5 working days; bulk production completes 7-15 days after artwork approval on ISO 9001 partner lines, with quotes back within 24 hours.
Ordering this product
Sampling, quotations and supply through Rivotag.
How fast will I get a quotation?
Can I get samples before ordering?
What is the production lead time?
Are you the manufacturer?
Can you customize size, chip, printing and encoding?
How is quality controlled?
