Jewelry UHF eco RFID label · 79×10 mm · NXP UCODE 9 (RT-E102)
A tailed 79x10 mm UHF label for jewelry and luxury goods management: the slender end folds over and hangs on the piece, a design that keeps tags from slipping off delicate items. The PP synthetic paper face wears well, and an NXP UCODE 9 chip with 37x8 mm antenna provides a 96-bit EPC over ISO/IEC 18000-6C.
At a glance
- RFID Chip
- NXP UCODE 9
- Label Size
- 79mm*10mm
- Protocol
- ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
- Memory
- 96-bit factory-locked TID (includes a 48-bit unique serial number), 96 bits EPC, 0 bit User Memory
- Face Material
- PP Synthesis Paper
- Product Model
- RT-E102
Quote reply within 24 hours
Free samples — freight collect
Share your quantity, surface, printing and encoding requirements. We’ll confirm the configuration, volume pricing and sample availability.
Supplied by Rivotag through partner production lines.Technical information
Full specifications
Catalogue values describe this construction. Confirm any changes to chip, size, material, printing or encoding in your quotation.
Overview
| Product Model | RT-E102 |
|---|---|
| RFID Chip | NXP UCODE 9 |
| Label Size | 79mm*10mm |
| Antenna Size | 37mm*8mm |
| Face Material | PP Synthesis Paper |
| Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
| Memory | 96-bit factory-locked TID (includes a 48-bit unique serial number), 96 bits EPC, 0 bit User Memory |
| Applications | Jewelry management, luxury goods management |
| Key Benefits | Fast reading,Multi-reading, Traceability |
Customized services Details
| Customizable Label Size | Yes |
|---|---|
| Printing | Thermal transfer printing，Silk Screen Printing，and other custom printing. |
| Data initialization | Encoding |
Storage Environment Requirements
| Operating Temperature/Humidity | -0～60℃ / 20%～80% RH |
|---|---|
| Storage Temperature/Humidity | 20～30℃ / 20%～60% RH |
| Shelf Life | 1 year in anti-static bag at 20～30℃ / 20% ～60% RH |
| ESD Voltage Immunity | 2 kV (HBM) |
| Bending Diameter | ＞ 50mm |
| Other application environment requirements | Your environmental requirements for RFID labels will affect our selection and design of labels. For example, if you are going to apply RFID labels to special environments: high temperature & low temperature environment; high acid & high alkaline environment, please inform our product design team that we will customize unique RFID products for you within 3 working days. |
- Applications
- Jewelry management, luxury goods management
- Key Benefits
- Fast reading,Multi-reading, Traceability
Lose the tag and you lose the record — a real hazard when labelling slippery chains and slim bracelets. This 79x10 mm label answers with a tail: its slender end folds over and hangs on the piece itself, holding fast where flat stickers work loose and drop away.
The face is PP synthetic paper, resilient against handling and moisture and part of our eco label range. Within it, an NXP UCODE 9 chip on a 37x8 mm antenna returns a 96-bit EPC and 96-bit factory-locked TID (includes a 48-bit unique serial number) over ISO/IEC 18000-6C (EPCglobal Class 1 Gen 2), letting staff reconcile a full display case in seconds without touching a single item. Rated operation spans 0 to 60 °C.
Ordering & customization
Tail length, overall size, chip, face material and printing can each be tuned, with EPC encoding and TID capture completed before dispatch. We reply to quotes within 24 hours, send free samples freight collect in 3-5 working days, and finish production runs 7-15 days after artwork approval on ISO 9001 partner lines.
Chip memory reference: NXP UCODE 9 specification.
