Validate this construction on your material with samples before a volume order.
UHF flexible on-metal RFID label · 65×35 mm · Impinj M830 (RT-M105)
A bendable anti-metal UHF label that restores read performance where standard tags go dark: up to 7 meters on metal surfaces from a 65×35×1 mm PET construction. The Impinj M830 chip supports around 10,000 rewrites, batches pass 100% Voyantic conformance testing, and the -40 to 85 °C rating suits IT assets, metal containers and spare parts.
At a glance
- RFID Chip
- Impinj M830
- Label Size
- 65mm*35mm*1mm( LxWxT)
- Protocol
- ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
- Memory
- EPC 128bits；User memory 0 bits
- Face Material
- PET
- Frequency range
- 860-960MHZ
Quote reply within 24 hours
Free samples — freight collect
Share your quantity, surface, printing and encoding requirements. We’ll confirm the configuration, volume pricing and sample availability.
Supplied by Rivotag through partner production lines.Technical information
Full specifications
Catalogue values describe this construction. Confirm any changes to chip, size, material, printing or encoding in your quotation.
Overview
| RFID Chip | Impinj M830 |
|---|---|
| Memory | EPC 128bits；User memory 0 bits |
| Label Size | 65mm*35mm*1mm( LxWxT) |
| Face Material | PET |
| Protocol | ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2 |
| Frequency range | 860-960MHZ |
| Reading distance | 7 meters（on metal） |
| Re-writeable | 10000 times |
| Conformance test | 100% pass Voyantic test |
Customized services Details
| Customizable Label Size | Yes |
|---|---|
| Printing | print text , barcode and QR code, color printing |
| Printer | Sato SATO CL4NX, Boside TX3R, Zebra ZT410 Silverline, ect. |
| Data initialization | Encoding |
Storage Environment Requirements
| Operating Temperature | -40～85℃ |
|---|---|
| Storage Temperature | -40～85℃ |
Metal reflects and detunes UHF signals, which is why ordinary labels go quiet the moment they touch a server chassis or steel pipe. This flexible on-metal label is engineered against that failure: a 1 mm thin, bendable 65×35 mm construction that conforms to curved surfaces — pipes, cylinders, equipment shells — while still reading up to 7 meters on metal.
The Impinj M830 chip provides a 128-bit EPC over ISO/IEC 18000-6C / EPCglobal Class 1 Gen 2 across 860–960 MHz, and can be rewritten around 10,000 times as assets change hands. The PET face accepts text, barcodes, QR codes and color printing on common industrial printers such as the SATO CL4NX and Zebra ZT410 Silverline; batches pass 100% Voyantic conformance testing, and operation is rated from -40 to 85 °C.
Where it fits
Office and IT asset registers, valuable electronic equipment, and tracking of metal containers and spare parts. We supply it from ISO 9001 partner lines with size, chip, face material, printing and EPC/TID encoding customized — quotes within 24 hours, free freight-collect samples in 3–5 working days, and production 7–15 days after artwork approval.
Ordering this product
Sampling, quotations and supply through Rivotag.
How fast will I get a quotation?
Can I get samples before ordering?
What is the production lead time?
Are you the manufacturer?
Can you customize size, chip, printing and encoding?
How is quality controlled?
